FRAME
365650b, Alloy 6069, triple butted tubes, T4, T6 on XS700c, Alloy 6069, triple butted tubes, T4, T6 on S, M, L, XL
FORK
365Internal brake hose routing, Alloy 6069
HEADSET
ACROS IS52 / IS52Integrated cable routing
STEM
RIDE ALPHA Gravel 7070 mm extension, 31.8 mm
HANDLEBAR
SPANK Flare 25 Drop Bar31.8 mm, 440 mm width, 65 mm reach, 110 mm drop, 25° flare on XS, S31.8 mm, 460 mm width, 65 mm reach, 110 mm drop, 25° flare on M31.8 mm, 480 mm width, 65 mm reach, 110 mm drop, 25° flare on L, XL
GRIPS
SPANK Wing Gravel Dropbar Tape & Plug220 cm, Black
BRAKES
SHIMANO GRX RX810, Flat Mount, resin padsRotors: SHIMANO RT-EM810 180 mm, Centerlock
SHIFTERS
SHIMANO GRX RX81011s
REAR DERAILLEUR
SHIMANO GRX RX81211s
BOTTOM BRACKET
SHIMANO BB72Pressfit
CRANKSET
SHIMANO GRX RX810, 170 mm crank arms on XS/S, 172.5 mm on M/L, 175 mm on XLChainring: SHIMANO GRX RX810, 40t
CASSETTE
SHIMANO Deore XT M800011s, 11-42t
RIMS
DT SWISS G1800 Spline — 650b, 24h, 24 mm inner width, 25 mm profile height on XS — 700c, 24h, 24 mm inner width, 25 mm profile height on S / M / L / XL
HUBS
Rear: DT SWISS 370 - Front: DT SWISS 370Rear: 24h, sealed bearings, 12 x 142 mm, Ratchet LN 18, Shimano Hyperglide - Front: 24h, sealed bearings, 12 x 100 mm
SPOKES/NIPPLES
DT SWISS aero compStraightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS Rambler - Front: MAXXIS RamblerRear & Front: 650x47b, EXO, Tubeless Ready on XS - 700x45c, EXO, Tubeless Ready on S / M / L / XL
SEAT POST
KINDSHOCK Lev Si27.2 mm, 65 mm travel on XS/S, 100 mm on M/L, 120 mm on XLThe saddle height (see 14 on geometry diagram) can be lowered by 20mm.
SADDLE
FIZIK Terra Alpaca X5145 mm width, S-alloy rails
WEIGHT
10,9 kg / 24.03 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Frozen BrownMatte Finish
ACCESSORIES
Down tube protector, chainstay protector, fork mudguard
