FRAME
CLASH, 170 mm travel — 27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
SHOCK
ROCKSHOX Deluxe Select — 230 x 65 mm, R damper, rebound
FORK
MARZOCCHI Bomber Z1, 170 mm travel — 27.5'', RAIL 2.0, Sweep-Adj, rebound, Boost (15 x 110 mm), 3 pos, 44 mm offset, 0 token
HEADSET
ACROS ZS44 / ZS56 — Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 — 40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R27 — 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA Mushroom — Ultra-soft compound, single clamp, black
BRAKES
SRAM DB4, 4 pistons, resin pads — Rotors: SRAM G2 200 mm, 6-bolt, 2.0 mm thickness
SHIFTERS
SHIMANO Deore — 12s
REAR DERAILLEUR
SHIMANO Deore — 12s
BOTTOM BRACKET
SHIMANO SM-BB-71 — Pressfit
CRANKSET
SHIMANO MT512, 165 mm crank arms — Chainring: SHIMANO MT512, 32t
CHAIN
SHIMANO Deore — 12s
CASSETTE
SHIMANO Deore — 12s, 10-51t
RIMS
DT SWISS E593 — 27.5'', 32h, 30 mm inner width
HUBS
Rear: FORMULA MSL-148A - Front: FORMULA DC-611 — Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Microspline - Front: 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
SAPIM Race — 2.0-1.8-2.0 mm, double butted, stainless, black
TYRES
Rear: MAXXIS Minion DHR II - Front: MAXXIS Assegai — Rear: 27.5" x 2.5", 3C MaxxTerra, Nexo + - Front: 27.5" x 2.5", 3C MaxxGrip, Nexo +
SEAT POST
RIDE ALPHA — 34.9 mm, 400 mm on S/M, 450 mm on L/XL
SADDLE
FIZIK Terra Alpaca X5 — 145 mm width, S-alloy rails
WEIGHT
15,5 kg / 34.17 lb — Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure White — Shiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
