FRAME
CLASH, 170 mm travel27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings
SHOCK
ROCKSHOX Super Deluxe Select230 x 65 mm, DebonAir Progressive, rebound
FORK
ROCKSHOX Zeb Base, 180 mm travel27.5", Rush RC damper, Debonair +, rebound, LSC, Boost (15 x 110 mm), 38 mm offset, 0 Token
HEADSET
ACROS ZS44/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 EXTERNAL40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI LongneckSoft compound, single clamp, black
BRAKES
SRAM DB8, 4 pistons, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 mm, 6-bolt
SHIFTERS
SRAM SX Eagle12s
REAR DERAILLEUR
SRAM SX Eagle12s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 34t, Narrow-Wide
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
E13 LG1 DH Base27.5'', 32h, 30 mm inner width
HUBS
Rear: FORMULA DCL-348A - Front: FORMULA DC-71132h, sealed bearings
SPOKES/NIPPLES
SAPIM RaceJ-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5"x2.4" WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 27.5"x2.5" WT, 3C MaxxGrip, EXO+, Tubeless Ready
SEAT POST
KS Rage-I34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote
SADDLE
SDG Bel Air V3Steel Rails
WEIGHT
15,5 kg / 34.17 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pyrite GreyShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, shuttle pad
