FRAME
CLASH, 170 mm travel27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings
SHOCK
FOX Float X2 Factory230 x 65 mm, HSC, LSC, HSR, LSR, 2-position adjustment (open / firm) lever
FORK
FOX 38 Factory, 180 mm travel27.5", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 37 mm offset, 1 spacer
HEADSET
ACROS ZS44/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 EXTERNAL40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI LongneckSoft compound, single clamp, black
BRAKES
TRP DH-R EVO, 4 pistons, resin padsRotors: TRP R1 203 mm, 6-bolt, 2.3 mm width
SHIFTERS
SRAM GX Eagle12s
REAR DERAILLEUR
SRAM GX Eagle12s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
SRAM GX Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM GX Eagle, 34t, Narrow-Wide
CASSETTE
SRAM XG-127512s, 10 - 52t
RIMS
DT SWISS EX 51127.5'', 28h, 30 mm inner width, Tubeless Ready
HUBS
Rear: DT SWISS 350 - Front: DT SWISS 350Rear: 28h, sealed bearings, 12 x 148 mm, SRAM XD, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black
SPOKES/NIPPLES
DT SWISS COMPETITIONStraightpull, 2.0-1.6-2.0 mm, double butted, stainless, with Nylok, black
TYRES
Rear: SCHWALBE Big Betty - Front: SCHWALBE Magic MaryRear: 27.5" x 2.4", Super Trail, Addix Soft - Front: 27.5" x 2.4", Super Trail, Addix Soft
SEAT POST
FOX Transfer Factory31.6 mm, 125 mm on S, 175 mm on M / L, 200 mm on XL, seatpost reducer
SADDLE
SDG Bel Air V3 Atmos140 mm width, Lux-Alloy Rails
WEIGHT
15,8 kg / 34.83 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
ACCESSORIES
FOX 38 specific fork fender, Down tube protector, chainstay protector, seatstay protector, shuttle pad
