FRAME
CLASH V3, 170 mm travel — 27.5'', Alloy 6066, triple butted tubes, T4, T6.
SHOCK
ROCKSHOX Super Deluxe Select — 230 x 65 mm, Pos adjustment, Rebound
FORK
ROCKSHOX Zeb Ultimate, 180 mm — 27.5'', Charger 3.2, HSC, LSC, HSR, LSR, Boost (15 x 110), 0 Token
HEADSET
ACROS ZS56 / ZS56 — Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 — 40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M - RIDE ALPHA R35 800 on L — 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M - 31.8 mm, 800 mm width, 35 mm rise, Alloy 6061 on L
GRIPS
RIDE ALPHA Mushroom — Single clamp, black
BRAKES
SRAM Maven Base, 4 pistons, sintered pads — Rotors : SRAM Centerline 200 mm, 6-bolts
SHIFTERS
SRAM EAGLE 90 — 12s
REAR DERAILLEUR
SRAM EAGLE 90 — 12s
BOTTOM BRACKET
SRAM DUB — BSA 73 MTB wide
CRANKSET
SRAM EAGLE 70, 165 mm — Chainring : SRAM EAGLE 90, 34t T-type
CHAIN
SRAM GX T-type — 12s
CASSETTE
SRAM XS 1270 T-type — 12s, 10-52t
RIMS
DT SWISS F1900 Classic — 27.5'', 32h, 30 mm inner width
HUBS
DT SWISS 370 Classic LN — Rear : 32h, sealed bearings, 12 x 148 mm, Hyperglide - Front : 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
DT SWISS Competition — J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear : SCHWALBE Tacky Chan - Front : SCHWALBE Magic Mary — Rear : 27.5x2.50, Gravity, Soft, Tubeless ready - Front : 27.5x2.50, Trail Pro, Soft, Tubeless ready
SEAT POST
KS Lev Integra — 34.9 mm, 150 mm on S, 175 mm on M, 200 mm on L
SADDLE
BURGTEC The Cloud boost — Alloy rails, Black
WEIGHT
- kg / - lbs — Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure White — Shiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, shuttle pad, fork mud guard, FIDLOCK base
