The META HT KIDS are the children's versions of our META HT. The geometries, components, and wheel sizes are designed as a complete package to help children become experienced riders.
We value contact with our customers. In the event of any issue, it will work with you to find a solution. Regardless of the delivery option you choose, all your purchases include free access to COMMENCAL CARE.
COMMENCAL CARE is our vision of customer service.
We value contact with our customers. In the event of any issue, it will work with you to find a solution. Regardless of the delivery option you choose, all your purchases include free access to COMMENCAL CARE.
COMMENCAL products are covered by our warranty to offer you peace of mind and allow you to fully enjoy your purchase. Our products undergo a rigorous testing process, but we understand that unexpected issues can arise. We will handle each case individually to provide you with a fair solution and help you get back to your activities quickly.
Specs
TECHNICAL INFORMATION
SPECIFICATION
DETAIL
BICYCLE TYPE
All Mountain
FRAME MATERIAL
AL 6061 T4, T6
FRAME WEIGHT
2,32 kg / 5,11 lb
RECOMMENDED/MAX. FORK HEIGHT
561mm / 571mm
HEADSET TYPE
ZS56 / ZS56
ICR COMPATIBLE
Yes
WHEELS SIZE
29’’ - 29’’ (M-L-XL) 29’’ - 27.5’’ (S)
MAX. REAR TYRE DIMENSION - ETRTO
64mm - Ø622mm (M-L-XL) 64mm - Ø584mm (S)
REAR BRAKE MOUNTING TYPE
Postmount 200mm
REAR BRAKE ROTOR MAX. SIZE
200mm
SEATPOST/SEAT CLAMP DIAMETER
31,6mm / 34,9mm
SEATPOST INSERTION MAX.
S : 300mm / M : 300mm / L : 320mm / XL : 340mm
BOTTOM BRACKET TYPE
BSA 68mm
CHAIN GUIDE
No
RECOMMENDED/MAX. CHAINRING TEETH
32T / 34T
CHAIN LINE
53
REAR HUB DIMENSION
148x12mm
REAR AXLE DIMENSION
UDH standard, 180mm, M12, P1.0mm
UDH HANGER
Yes
Geometry
GEOMETRY
MEASUREMENT
S
M
L
XL
1 - SEAT TUBE LENGTH
380
420
440
460
2 - SEAT TUBE ANGLE
76,8°
75,5°
75,5°
75,5°
3 - HEAD TUBE ANGLE
65,8°
64,5°
64,5°
64,5°
4 - HEAD TUBE LENGTH
115
120
125
130
5 - WHEELBASE
1150
1196
1218
1246
6 - TOP TUBE LENGTH
558
603
624
650
7 - CHAIN STAY LENGTH
425
430
430
430
8 - BOTTOM BRACKET HEIGHT
-54,4
-50
-50
-50
9 - FORK LENGTH
561
561
561
561
10 - REACH
410
435
455
480
11 - STACK
638
649
653
658
Besoin d'aide pour choisir le bon produit?
Notre équipe de riders et d'experts se fera un plaisir de t'aider.
Specs
Taille
Métrique
Impérial
Voici un tableau des tailles.
Géo
Métrique
Impérial
Géométrie de ce vélo.
Reach
longueur à l'horizontal entre le milieux du BB et le milieux du dessus headtube.
Stack
Hauteur a la vertical entre le BB et le dessus du headtube.
Effective Top Tube
Longueur à l'horizontal entre le milieux du seatube et milieux du dessus du headtube.
Actual Top Tube
Longueur réel du entre le milieux du headtube et le milieux du seat tube.
Standover Height
la hauteur du centre du toptube vs du sol.
Seat Tube Angle
Angle du seat tube.
Seat Tube Length
Longueur du seat tube prise du BB (Bottom Bracket) jusqu'au sommet du seat tube (la mesure est prise parallèlement au seat tube)
Headtube Angle
Angle du headtube.
Headtube
La longueur du headtube.
Chainstay
Longueur entre l'axe de roue arr. et du BB (Bottom Bracket).
Wheelbase
Longueur à l'horizontal entre les deux axes de roues.
BB Height
Hauteur entre le sol et le BB (Bottom Bracket).
BB Drop
Longueur à la vertical entre la hauteur moyenne des axes de roue et la hauteur du BB.
