FRAME
2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XLAlloy 6061, triple butted tubes, T4, T6.
FORK
ROCKSHOX Yari RC, 150 mm travel29", Motion Control damper, DebonAir, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens
HEADSET
ACROS ZS44 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA Freeride 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 on S - RIDE ALPHA R27 on M / L / XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
SRAM Guide T, 4 pistons, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt
SHIFTERS
SRAM NX Eagle12s
REAR DERAILLEUR
SRAM NX Eagle12s
BOTTOM BRACKET
SRAM BSAThreaded
CRANKSET
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
SPANK Spike Race 33Rear: 27.5'', 32h, 28 mm inner width on S / M - 29'', 32h, 28 mm inner width on L / XL - Front: 29'', 32h, 28 mm inner width on S / M / L / XL
HUBS
Rear: FORMULA DC-348A - Front: FORMULA DC-711Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
SAPIM LeaderJ-Bend 2.0 mm, stainless, with Nylok, black
TYRES
Rear: MAXXIS Dissector - Front: MAXXIS DissectorRear: 27.5'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on S / M - 29'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on L / XL - Front: 29" x 2.6", 3C MaxxTerra, EXO+, Tubeless Ready on S / M / L / XL
SEAT POST
KS Rage-I31.6 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote
SADDLE
FIZIK Terra Alpaca X5145 mm width, S-alloy rails
WEIGHT
14,2 kg / 31.30 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Keswick GreenShiny Finish
ACCESSORIES
Chainstay protector, seatstay protector
