FRAME
META HT V3: 29''/27'' on S & 29''/29'' on M / L / XLAlloy 6061, triple butted tubes, T4, T6.
FORK
FOX 36 Factory, 150 mm travel29", Grip X2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset
HEADSET
ACROS ZS56/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 mm40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA Mushroom132 mm, black clamp
BRAKES
SRAM DB8, 4 pistonsRotors: SRAM G2 200 mm, 6-bolts
SHIFTERS
SRAM Eagle 9012s
REAR DERAILLEUR
SRAM Eagle 9012s
BOTTOM BRACKET
SRAM DUB BSAWidth 68 mm, wide
CRANKSET
SRAM Eagle 70, 170 mm crank armsChainring: SRAM Eagle 70, 32t, steel
CASSETTE
SRAM Eagle 7012s, 10-52t, Sram HG
RIMS
DT SWISS EX511Rear: 27.5'', 32h, 30 mm inner width on S or 29'', 32h, 30 mm inner width on M / L / XL - Front: 29'', 28h, 30 mm inner width on S / M / L / XL
HUBS
DT SWISS 370Rear: 32h, sealed bearings, 12 x 148 mm, SRAM HG - Front: 28h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
DT SWISS ChampionJ-Bend
TYRES
Rear: MAXXIS DHRII - Front: MAXXIS AssegaiRear: S: 27.5 x 2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ - M / L / XL: 29 x 2.50 WT MINION DHR II 3C MaxxTerra, New EXO+
SEAT POST
KS Rage-I31.6 mm, travel: 150 mm on S, 170 mm on M, 190 mm on L/XL
SADDLE
FIZIK Terra Aidon X5145 mm width, S-alloy rails
WEIGHT
14 kg / 30.86 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure WhiteShiny finish
ACCESSORIES
Downtube protector, chainsuck, chainstay protector, seatstay protector, fork mud guard, FIDLOCK base
