FRAME
META POWER SX 400, 170 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
MOTOR
BOSCH Performance Line SXMax. torque: 60 N.m, 250 W
BATTERY
BOSCH Compact Powertube 400Fully integrated main battery, 400 WhBOSCH 4A Battery Charger. Compact size & lightweight
DISPLAY
BOSCH System ControllerON/OFF switch, assist mode level, battery charge level
SHOCK
FOX Float X Performance230 x 65 mm, 2-position (open/firm) lever, LSR, LSC, 0.4 spacers
FORK
FOX 38 Performance E-Bike, 170 mm29", Fit Grip damper, 3 positions compression, rebound, Boost (15 x 110 mm), 44 mm offset, 3 spacers
HEADSET
ACROS ZS56 / ZS66Alloy cups, stainless steel & sealed bearings
STEM
RIDE ALPHA 4040 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA MushroomSoft compound, single clamp, 132 mm width, black
BRAKES
TRP DH-R EVO PRO, 4 pistons, resin padsRotors: TRP R2 203 mm, 6-bolt, 2.3 mm width
SHIFTERS
SRAM Eagle 9012s
CHAIN GUIDE
RIDE ALPHA32-34t
REAR DERAILLEUR
SRAM Eagle 9012s
CRANKSET
E13 Helix Core E*Spec, 155 mm crank arms, Bosch Gen4Chainring: E13 Helix Race 34T, 34t, direct mount, Bosch Gen4
CASSETTE
SRAM XS 1270 T-Type12s, 10-52t
RIMS
DT SWISS HF1900 — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
DT SWISS 370 — Rear: 32h, sealed bearings, 12 x 148 mm, 18t, Sram XD - Front: 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
Included with wheelset
TYRES
Rear: MAXXIS Minion DHRII 27.5'' - Front: MAXXIS ASSEGAI 29''Rear: 27.5 x 2.50 WT, Tubeless Ready, 3C MaxxTerra, Double Down - Front: 29 x 2.50 WT, Tubeless Ready, 3C MaxxGrip, New EXO+
SEAT POST
KS Rage-I34.9 mm, 125 mm on S, 170 mm on M and 190 mm on L/XL
SADDLE
FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails
WEIGHT
22.0 kg / 48.50 lbsMinimum weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
CRANKBROTHERS Stamp 1
COLOUR
Pure BlackShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, FOX 38 specific fender, FIDLOCK base
