FRAME
META POWER SX 400, 170 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu Bearings
MOTOR
BOSCH Performance Line SXMax. torque: 60 N.m, 250 W
BATTERY
BOSCH Compact Powertube 400Fully integrated main battery, 400 WhBOSCH 4A Battery Charger. Compact size & lightweight
DISPLAY
BOSCH System ControllerON/OFF switch, assist mode level, battery charge level
SHOCK
FOX Float X Factory230 x 65 mm, 2-postion (open/firm) lever, LSC, LSR, 0.4 spacers
FORK
FOX 38 Factory E-Bike, 170 mm29", Grip X2 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset, 3 spacers
HEADSET
ACROS ZS56 / ZS66Alloy cups, stainless steel & sealed bearings
STEM
RIDE ALPHA 4040 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Longneck 2.1Soft compound, single clamp, black
BRAKES
SRAM MAVEN Silver, 4 pistons, steel-backed organic padsRotors: SRAM HS2 200mm, 6-bolt
SHIFTERS
SRAM AXS POD Controller12s
CHAIN GUIDE
RIDE ALPHA32-34t
REAR DERAILLEUR
SRAM GX Eagle Transmission12s, AXS, T-Type
CRANKSET
SRAM X0 Eagle E-MTB, 155 mm crank arms, BoschChainring: SRAM XX Eagle Transmission E-MTB, 34t for Bosch system Gen 4, direct mount, T-Type
CHAIN
SRAM GX Eagle Transmission12s, Flattop, T-Type
CASSETTE
SRAM GX Eagle Transmission12s, 10-52t, T-Type
RIMS
DT SWISS HFR1700 Classic — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
DT SWISS 350 — Rear: 32h, sealed bearings, 12 x 148 mm, 24t, Sram XD, e-bike specific - Front: 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
DT SWISS Hybrid 3Straightpull, 2.34/2.0 mm, double butted, stainless, with ProLock, black
TYRES
Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic MaryRear: 27.5'' x 2.4'', Super Gravity, Addix Soft, Tubeless Easy- Front: 29" x 2.4'', Super Trail, Addix Ultra Soft, Tubeless Easy
SEAT POST
FOX Transfer Factory34.9 mm, 150 mm on S, 180 mm on M and 210 mm on L/XL
SADDLE
FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails
WEIGHT
21,9 kg / 48.28 lbsMinimum weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
CRANKBROTHERS Stamp 1
COLOUR
Glittery WhiteShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, FOX 38 specific fender, FIDLOCK bases, down tube plastic film protector
