FRAME
META POWER SX V4, 165 mm travel29"-27.5", Alloy 6066, triple butted tubes, T4, T6.
MOTOR
BOSCH Performance Line CXMax. torque: 85N.m, 250W
BATTERY
BOSCH PowerTube 625, 625WhBOSCH 4A Charger, Compact size & lightweightCompatible w/BOSCH PowerMore 250 for extra range
DISPLAY
BOSCH System ControllerBOSCH Mini Remote currently not available in the USA
SHOCK
ROCKSHOX Deluxe Select230 x 65 mm, R damper, DebonAir, rebound, 1 Token neg. 4 Tokens pos.
FORK
ROCKSHOX Domain RC, 170 mm travel29'', Motion Control damper, DebonAir, rebound, LSC, Boost (15 x 110 mm), 44 mm offset, 1 Token
HEADSET
ACROS ZS56 / ZS66Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 EXTERNAL40 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XLInternal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
SRAM Guide RE, 4 pistons, steel-backed metal sintered padsRotors: SRAM HS2 220 mm, 6-bolt
SHIFTERS
SRAM SX Eagle12s
CHAIN GUIDE
RIDE ALPHA Upper Guide32-34t
REAR DERAILLEUR
SRAM SX Eagle12s
CRANKSET
E13 E*Spec Plus BOSCH CX, 160 mm crank armsChainring: E13 E*Spec Plus BOSCH CX, 34t, direct mount
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
Rear: SPANK Spike Race 33 - Front: SPANK Spike Race 33Rear: 27.5'', 32h, 28 mm inner width rear - Front: 29'', 32h, 28 mm inner width front
HUBS
Rear: FORMULA eHL-148S - Front: FORMULA DC-711Rear: 32h, 12 x 148 mm, sealed bearings, e-bike specific, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
SAPIM StrongJ-Bend, 2.34/2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5" x 2.4" WT, 3C Maxx Terra, Double Down, Tubeless Ready - Front: 29" x 2.5" WT, 3C Maxx Grip, Exo+, Tubeless Ready
SEAT POST
KS Rage I31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remote
SADDLE
FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails
WEIGHT
25 kg / 55.12 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
RIDE ALPHA CNC
COLOUR
Pyrite GreyShiny Finish
ACCESSORIES
Motor protector, chainstay protector, seatstay protector,
