FRAME
META V5, 150 mm travel29'', Alloy 6066, triple butted tubes, T4, T6
SHOCK
ROCKSHOX Deluxe Select +210 x 55 mm, RT damper, DebonAir, rebound, 2 position compression, 0 Token neg. 3 Tokens pos.
FORK
ROCKSHOX Lyrik Base, 160 mm travel29", Rush RC damper, DebonAir+, LSC, rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token
HEADSET
ACROS ZS56 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI LongneckSoft compound, single clamp, black
BRAKES
SRAM DB8, 4 pistons, steel-backed organic pads, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 mm, 6 holes
SHIFTERS
SRAM NX Eagle12s
CHAIN GUIDE
RIDE ALPHA32t-34t
REAR DERAILLEUR
SRAM NX Eagle12s
BOTTOM BRACKET
SRAM DUB WIDEPressfit
CRANKSET
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM Eagle, 32t, Narrow-Wide
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
SPANK SPIKE RACE 3329'', 32h, 28 mm inner width
HUBS
Rear: FORMULA DCL-348A - Front: FORMULA DC-711Rear: 32h, 12 x 148 mm, sealed bearings, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
SAPIM RaceJ-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS DHR IIRear: 29"x2.40" WT, EXO, Dual, Tubeless Ready - Front: 29"x2.40" WT, EXO, 3C MaxxGrip, Tubeless Ready
SEAT POST
KS Rage-i34.9 mm, travel: 125 mm on S, 170 mm on M/L and 190 mm on XL, SouthPaw alloy remote
SADDLE
SDG Bel Air V3140 mm width, steel rails
WEIGHT
15,9 kg / 35.05 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pyrite GreyShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
