FRAME
SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL27/29'', Alloy 6066, triple butted tubes, T4, T6
SHOCK
FOX DHX 2 Performance Elite250 x 75 mm, LSC, LSR. Spring rates: 400 lbs on S, 450 lbs on M, 500 lbs on L, 500 lbs on XL
FORK
FOX 40 Performance, 203 mm travel29", Grip damper, LSC, Float Evol. Boost (20 x 110 mm), 52 mm offset, 2 spacers
HEADSET
ACROS ZS56 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA DH 4040 mm extension, direct mount, 31.8 mm
HANDLEBAR
RIDE ALPHA R2731.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI LongneckSoft pro compound, single clamp, black
BRAKES
TRP DH-R Evo, 4 pistons, resin padsRotors : TRP R1 223 mm, 6-bolt, 2.3 mm thickness
CHAIN GUIDE
E13 LG1 + Bottom Guide32-34t
REAR DERAILLEUR
SRAM GX DH7 sp
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
TRUVATIV Descendant DH, 165 mm crank arms, DUBChainring: TRUVATIV Descendant DH X-Sync, 34t
CASSETTE
E13 DH 7 Speed Integrated Cassette7s, 9-21t DM Cassette
RIMS
E13 Grappler Core Alloy DH — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
Rear: E13 LG1 PLUS DH - Front: E13 LG1 PLUS DHRear : E13 Grappler Core Alloy DH - Front : E13 Grappler Core Alloy DH
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5'' x 2.4'', WT, 3C MaxxGrip, DH casing, Tubeless Ready - Front: 29" x 2.5" WT, 3C MaxxGrip, DH casing, Tubeless Ready
SEAT POST
RIDE ALPHA Super Light31.6 mm, 250 mm length
SADDLE
FIZIK Gravita Alpaca X5130 mm width, S-Alloy rails
WEIGHT
17,5 kg / 38,58 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Aqua BlueShiny Finish
ACCESSORIES
Chainstay protector, seatstay protector, fork bumpers, downtube protector, roller cover, FOX 40 fork fender
