FRAME
SUPREME DH V5, 220 mm travel 29/27.5'', Alloy 6066, triple butted tubes, T4, T6
SHOCK
ROCKSHOX Super Deluxe Select R250 x 75 mm, R damper, DebonAir, rebound, Debonair, 1 token 0 Token neg. 3 Tokens pos.
FORK
ROCKSHOX Boxxer, 200 mm travel29", Charger RC damper, DebonAir, LSC, rebound, Boost (20 x 110 mm), 56 mm offset, 0 Token
HEADSET
ACROS ZS56 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA DH 4040 mm extension, direct mount, 31.8 mm
HANDLEBAR
RIDE ALPHA R2731.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
TRP DH-R Evo, 4 pistons, resin padsRotors: TRP R1 223 mm, 6-bolt, 2.3 mm width
CHAIN GUIDE
E13 LG1 + Bottom Guide32-34t
REAR DERAILLEUR
SRAM GX DH7 sp
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
TRUVATIV Descendant DH, 165 mm crank arms, DUBChainring: TRUVATIV Descendant DH X-Sync, 34t
CASSETTE
SRAM PG-7207 sp, 11-25t
RIMS
SPANK 359 — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
Rear: FORMULA DHG-157 - Front: FORMULA DHL-93Rear: 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm Boost, black
SPOKES/NIPPLES
SAPIM RaceJ-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5'' x 2.4'', WT, 3C MaxxGrip, DH casing, Tubeless Ready - Front: 29" x 2.5" WT, 3C MaxxGrip, Double Down, Tubeless Ready
SEAT POST
RIDE ALPHA Super Light31.6 mm, 250 mm, Alloy 7075
SADDLE
FIZIK Gravita Alpaca X5130 mm width, S-Alloy rails
WEIGHT
17,5 kg / 38,58 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Frozen BrownMatte Finish
ACCESSORIES
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard
