Commencal

COMMENCAL T.E.M.P.O. POWER ESSENTIAL

SKU:BT4TEMPWEUS1S

$7,500.00

En stock

Size - Bikes

Livraison gratuite

Saute dessus!

Testé et approuvé

par nos riders

Livraison rapide

Pour mieux rider!

Share on :

Aperçu

Description du produit

Overview

The T.E.M.P.O. POWER ESSENTIAL is the perfect toy that just keeps going.• The FOX 36 Performance fork with precise e-bike chassis and Grip cartridge is very easy to tune.• Braking is handled by the consistent and precise SHIMANO Deore 4-piston brakes.• New DT SWISS H 1900 LS (Light Support) wheels are ideal for the T.E.M.P.O. POWER. Hand-built and designed for mid-assist e-bikes to offer durability and responsiveness.• The 12-speed SHIMANO Deore drivetrain is known for its effectiveness and reliability.

Specs

TECHNICAL INFORMATION

SPECIFICATION

DETAIL

BICYCLE TYPE

E-bike - Trail

FRAME MATERIAL

AL 6069 T6

FRAME WEIGHT

3,84 kg / 8,46 lb

REAR TRAVEL

135mm

SHOCK LENGTH/STROKE

210x50mm

RECOMMENDED SAG

25-27% / 14-16mm

PIGGY BACK SHOCK COMPATIBLE

Yes

SHOCK BUSHINGS

20x10mm - 30x10mm

RECOMMENDED/MAX. FORK HEIGHT

551mm / 561mm

HEADSET TYPE

ZS56 / ZS56

ICR COMPATIBLE

Yes

WHEELS SIZE

29’’ - 29’’

MAX. REAR TYRE DIMENSION - ETRTO

65mm - Ø622mm

REAR BRAKE MOUNTING TYPE

Postmount 200mm

REAR BRAKE ROTOR MAX. SIZE

203mm

SEATPOST/SEAT CLAMP DIAMETER

31,6mm / 34,9mm

SEATPOST INSERTION MAX.

S : 225mm / M : 265mm / L : 285mm / XL : 305mm

MOTOR CRANKARMS INTERFACE

BOSCH SX

CHAIN GUIDE

Custom upper guide

RECOMMENDED/MAX. CHAINRING TEETH

32T / 34T

CHAIN LINE

REAR HUB DIMENSION

148x12mm

REAR AXLE DIMENSION

UDH standard, 180mm, M12, P1.0mm

UDH HANGER

yes

Geometry

GEOMETRY

MEASUREMENT

1 - SEAT TUBE LENGTH

380

420

440

460

2 - SEAT TUBE ANGLE

76,3°

3 - HEAD TUBE ANGLE

65°

4 - HEAD TUBE LENGTH

115

120

125

130

5 - WHEELBASE

1202,2

1224,4

1246,5

1270,5

6 - TOP TUBE LENGTH

576,5

597,8

619,1

640,4

7 - CHAIN STAY LENGTH

445

8 - BOTTOM BRACKET HEIGHT

-27

9 - FORK LENGTH

561

10 - FORK OFFSET

11 - REACH

426

446

466

486

12 - STACK

623

627,5

632

636,5

Build Specs

SPECIFICATIONS

SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION

COMPONENT

SPECIFICATION

FRAME

T.E.M.P.O. POWER, 135 mm travel29'', Alloy 6066 triple butted tubes, T4, T6. Bolu bearings

MOTOR

BOSCH Performance Line SXMax. torque: 60 N.m, 250 W

BATTERY

BOSCH PowerTube 400Integrated, 400 WhBOSCH 4A Battery Charger. Compact size & lightweight

DISPLAY

BOSCH System ControllerON/OFF switch, assist mode level, battery charge level

SHOCK

FOX Float Performance210 x 50 mm, rebound, 2-postion (open/firm) lever, 3-setting open mode tuning range, 0.6 spacers

FORK

FOX 36 Performance E-Bike, 150 mm29", Grip damper, rebound, LSR, 3-position compression, Boost (15 x 110 mm), 44 mm offset, 4 spacers

HEADSET

ACROS ZS56 / ZS56Alloy cups, sealed & stainless steel bearings

STEM

RIDE ALPHA 4040 mm extension, 31.8 mm

HANDLEBAR

RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

RIDE ALPHA MushroomSoft compound, single clamp, 132 mm width, black

BRAKES

SHIMANO Deore, 4 pistons, resin padsRotors: SHIMANO SM-RT86 203 mm, 6-bolt

SHIFTERS

SHIMANO Deore12s

CHAIN GUIDE

RIDE ALPHA32-34 T

REAR DERAILLEUR

SHIMANO Deore12s

CRANKSET

E13 Helix Core e*spec, 155 mm crank armsRotors: E13 Helix Race e*spec, 34t, direct mount

CHAIN

SHIMANO Deore12s

CASSETTE

SHIMANO Deore12s, 10-51t

RIMS

DT SWISS H 1900 LS29'', 28h, 30 mm inner width, Tubeless Ready

HUBS

DT SWISS 370Rear: 28h, 12 x 148 mm, sealed bearings, 18t, e-bike specific, Shimano Hyperglide - Front: 28h, 15 x 110 mm, sealed bearings

SPOKES/NIPPLES

DT SWISS Hybrid 1Straightpull, 2.34 / 2.0 mm, double butted, stainless, with ProLock, black

TYRES

Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic MaryRear: 29"x2.4", Evo, Super Trail, Addix Soft, Tubeless Easy - Front: 29"x2.4", Evo, Super Trail, Addix Ultra Soft, Tubeless Easy

SEAT POST

KS Ragei31.6 mm, 125 mm on S, 170 mm on M, 190 mm on L /XL

SADDLE

FIZIK Terra Ridon X5145 mm width, S-Alloy Mobius rails

WEIGHT

20,4 kg / 45 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

CRANKBROTHERS Stamp 1

COLOUR

Glittery BlackShiny Finish

ACCESSORIES

Down tube protector, chainstay protector, seatstay protector, pedals, FOX 36 specific fender, Fidlock bases, down tube plastic film protector
