FRAME
TEMPO P.O.W.E.R., 135 mm travel29'', Alloy 6066 triple butted tubes, T4, T6. Bolu bearings
MOTOR
BOSCH Performance Line SXMax. torque: 60 N.m, 250 W
BATTERY
BOSCH PowerTube 400Integrated, 400 WhBOSCH 4A Battery Charger. Compact size & lightweight
DISPLAY
BOSCH System Controller, ON/OFF switch, assist mode level, battery charge levelSwitch: BOSCH Mini Remote, mode switch, walk assist, light switch
SHOCK
FOX Float Performance210 x 50 mm, rebound, 2-postion (open/firm) lever, 3-setting open mode tuning range, 0.6ci spacers
FORK
FOX 36 Performance E-Bike, 150 mm29", Grip damper, rebound, LSR, 3-position compression, Boost (15 x 110 mm), 44 mm offset, 4 spacers
HEADSET
ACROS ZS56/ZS56Alloy cups, sealed & stainless steel bearings
STEM
RIDE ALPHA 4040 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA MushroomSoft compound, single clamp, 132 mm width, black
BRAKES
SRAM DB8, 4 pistons, resin padsRotors: SRAM HS2 200 mm, 6-bolt, 2.0 mm width
SHIFTERS
SRAM Eagle 9012s
CHAIN GUIDE
RIDE ALPHA32-34 T
REAR DERAILLEUR
SRAM Eagle 9012s
CRANKSET
E13 Helix Core e*spec, 155 mm crank armsChainring: E13 Helix Race e*spec, 34t, direct mount
CASSETTE
SRAM XS 1270 T-Type — 12s, 10-52t
RIMS
DT SWISS M190029'', 28h, 30mm inner width, Tubeless Ready
HUBS
DT SWISS 370 — Rear: 28h, 12 x 148 mm, sealed bearings, 18t, Shimano Hyperglide - Front: 28h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
Included with wheelset
TYRES
Rear: MAXXIS DHRII - Front: MAXXIS Assegai — Rear: 29 x 2.40WT, 3C MaxxTerra, NEXO +, TR - Front: 29 x 2.50WT, 3C MaxxTerra, EXO, TR
SEAT POST
KS Ragei31.6 mm, 150 mm on S, 170 mm on M, 190 mm on L /XL
SADDLE
FIZIK Terra Aidon X5145 mm width, S-Alloy Mobius rails
WEIGHT
20,4 kg / 45 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
CRANKBROTHERS Stamp 1
COLOUR
Glittery BlackShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, pedals, FOX 36 specific fender, Fidlock bases, down tube plastic film protector
