All-new 38mm chassis equipped with the DebonAir+ twin tube air spring that will have you thinking it’s a coil
DebonAir+ twin tube air spring strikes the perfect balance between butter-smooth small bump feel, added support throughout the travel, and taller ride height for confidence when things get steep.
NEW Signature colorway BoXXer Electric Red with an all-new graphics package.
Premium fender compatibility (RockShox Bolt-On Fender included with purchase)
Short and tall crown options available to accommodate different head tube lengths.
Charger 3 damper tuned for BoXXer’s updated chassis and spring. Featuring High Speed Compression, Low Speed Compression, and a revamped Low Speed Rebound, every click is meaningful and exact.
ButterCups block 20% of high-frequency “trail chatter” to reduce hand and arm fatigue
SRAM Model ID: FS-BXR-ULT-D1
Attributes
Brake Type
Disc
Damping
Charger 3 RC2 W/ButterCups
Damping Adjustments
External begin stroke rebnd, low speed comp, high speed comp
Crown Material
Aluminum
Maximum Rotor Size
220mm
Maximum Tire Width
81mm
Spring Adjustments
Air pressure, Bottomless tokens
Spring Type
DebonAir+ W/ButterCups
Steerer Tube
1-1/8''
Steerer Tube Material
Aluminum
Lower Tubes Material
Magnesium
Stanchions Material
Aluminum
Travel
200mm
Stanchions Diameter
38mm
Axle/Hub spacing
20x110mm Boost TA
e-Bike approved
Yes
Need help choosing the right product?
Our team of riders and experts will be pleased to help you.
Specs
Size
Metric
Imperial
This is a size chart.
Geo
Metric
Imperial
Geometry of this bike.
Reach
Horizontal measurement taken from the middle of the bottom backet to the middle of the headtube.
Stack
Vertical measurement taken from the middle of the bottom bracket to the middle of the headtube.
Effective Top Tube
Horizontal measurement taken from the middle of the seatube to the middle of the headtube.
Actual Top Tube
True length of the top tube taken from the seatube along the toptup to the headtube.
Standover Height
Vertical measurement taken from the ground to the the middle of toptube.
Seat Tube Angle
Angle of the seatube.
Seat Tube Length
Lenght of the seat tube taken from the bottom bracket to the top of the seat tube (the measure is taken alongside the seat tube)
Headtube Angle
Angle of the headtube.
Headtube
Vertical lenght of the headtube.
Chainstay
Horizontal measurement taken from rear axle to the bottom bracket.
Wheelbase
Horizontal measurement between the two wheel axles.
BB Height
Vertical measurement taken from the ground to the bottom bracket (Never taken at sag).
BB Drop
Vertical measurement between the height of the axles and the height of the bottom bracket.
