FRAME
365650b, Alloy 6069, triple butted tubes, T4, T6 on XS700c, Alloy 6069, triple butted tubes, T4, T6 on S, M, L, XL
FORK
365Internal brake hose routing, Alloy 6069
HEADSET
ACROS IS52 / IS52Integrated cable routing
STEM
RIDE ALPHA Gravel 7070 mm extension, 31.8 mm
HANDLEBAR
SPANK Flare 25 Drop Bar31.8 mm, 440 mm width, 65 mm reach, 110 mm drop, 25° flare on XS, S31.8 mm, 460 mm width, 65 mm reach, 110 mm drop, 25° flare on M31.8 mm, 480 mm width, 65 mm reach, 110 mm drop, 25° flare on L, XL
GRIPS
SPANK Wing Gravel Dropbar Tape & Plug220 cm, Black
BRAKES
SHIMANO GRX RX400, Flat Mount, resin padsRotors: SHIMANO SM-RT66 180 mm, 6-bolt
SHIFTERS
SHIMANO GRX RX60011s
REAR DERAILLEUR
SHIMANO GRX RX81211s
BOTTOM BRACKET
SHIMANO BB-RS500Pressfit
CRANKSET
SHIMANO GRX RX600, 170 mm crank arms on XS/S, 172.5 mm on M/L, 175 mm on XLChainring: SHIMANO GRX RX600, 40t
CASSETTE
SHIMANO Deore M510011s, 11-42t
RIMS
DT SWISS G540 — 650b, 24h, 24 mm inner width, tubeless ready on XS — 700C, 24h, 24 mm inner width, tubeless ready on S / M / L / XL
HUBS
Rear: FORMULA RX-300 - Front: FORMULA RX-812Rear: 24h, sealed bearings, 12 x 142 mm, Shimano Hyperglide - Front: 24h, sealed bearings, 12 x 100 mm
SPOKES/NIPPLES
SAPIM RaceJ-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS Rambler - Front: MAXXIS RamblerRear & Front: 650x47b, EXO, Tubeless Ready on XS - 700x45c, EXO, Tubeless Ready on S / M / L / XL
SEAT POST
RIDE ALPHA27.2 mm, 350 mm length
SADDLE
FIZIK Terra Alpaca X5145 mm width, S-alloy rails
WEIGHT
10,9 kg / 24.03 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
ACCESSORIES
Down tube protector, chainstay protector, fork mudguard
