FRAME
CLASH, 170 mm travel27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings
SHOCK
FOX DHX2 Factory230 x 65 mm, HSC, LSC, HSR, LSR. 2-position (open / firm) lever. Spring rates : 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL.
FORK
FOX 38 Factory, 180 mm travel27.5", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 37 mm offset, 1 spacer
HEADSET
ACROS ZS44/ZS56Alloy cups, sealed bearings
STEM
TITLE ST1 3540 mm extension, 35 mm, Alloy 6061 T6, oil slick stainless steel bolts
HANDLEBAR
TITLE AH1 3535 mm, 810 mm width, 20 mm rise, Alloy 7050 T74
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
SHIMANO XT, 4 PISTONS, I-SPECS EV COMPATIBLE OR TRP DH-R EVO, 4 PISTONSRotors: SHIMANO SM-RT86 203 mm, 6-bolt, Ice Technology Freeza or TRP R1 203mm, 6-bolt, 2.3 mm
CHAIN GUIDE
E13 TRS30 - 32t
REAR DERAILLEUR
SRAM GX DH7s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
TRUVATIV Descendant, 165 mm crank arms, DUBChainring: TRUVATIV Descendant X-Sync, 32t
CASSETTE
SRAM GX DH7s, 11 - 25t
RIMS
SPANK Spike Race 3327.5'', 32h, 28 mm inner width, Tubeless Ready
HUBS
Rear: SPANK Spike - Front: SPANK SpikeRear: HEX J-Type, 32h, 2 sealed bearings, 12 x 148 mm, XD, black - Front: HEX J-Type, 32h, 2 sealed bearings, 15 x 110 mm, black
SPOKES/NIPPLES
SPANK J-HookJ-Bend, tripple butted 2.2/1.8/2.0, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5" x 2.4", WT, 3C MaxxTerra, Double Down, Tubeless Ready - Front: 27.5" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless Ready
SEAT POST
SDG Micro I-Beam31.6 mm, 250 mm length
SADDLE
SDG Patriot I-Beam31.6 mm, 250 mm length, diameter reducer
WEIGHT
15,6 kg / 34.39 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
METALLIC PURPLEMatte Finish
ACCESSORIES
down tube protector, chainstay protector, seatstay protector, shuttle pad, specific fox 38 fender
