Specs
TECHNICAL INFORMATION
SPECIFICATION
DETAIL
BICYCLE TYPE
Dirt / Pumptrack
FRAME MATERIAL
AL 6061 T4, T6
FRAME WEIGHT
1,9 kg / 4.18 lb
RECOMMENDED/MAX. FORK HEIGHT
470mm / 485mm
HEADSET TYPE
ZS44 / ZS56
WHEELS SIZE
26’’ - 26’’
MAX. REAR TYRE DIMENSION - ETRTO
61mm - Ø559mm
REAR BRAKE MOUNTING TYPE
IS 160mm
REAR BRAKE ROTOR MAX. SIZE
160mm
SEATPOST/SEAT CLAMP DIAMETER
31,6mm - 34,9mm
SEATPOST INSERTION MAX.
230mm
BOTTOM BRACKET TYPE
BSA 73mm
RECOMMENDED/MAX. CHAINRING TEETH
28T / 30T
CHAIN LINE
47,5
REAR HUB DIMENSION
135x10mm
REAR AXLE DIMENSION
Threaded rod, 180mm, M10
Geometry
GEOMETRY
MEASUREMENT
24
S
M
L
1 - SEAT TUBE LENGTH
270
310
310
310
2 - SEAT TUBE ANGLE
72,5°
72°
72°
72°
3 - HEAD TUBE ANGLE
69°
69°
69°
69°
4 - HEAD TUBE LENGTH
115
120
120
120
5 - WHEELBASE
972
1037
1057
1082
6 - TOP TUBE LENGTH
516
577
597
622
7 - CHAIN STAY LENGTH
365
390
390
390
8 - BOTTOM BRACKET HEIGHT
-8
-25
-25
-25
9 - FORK LENGTH
460
470
470
470
10 - REACH
360
395
415
440
11 - STACK
527
566
566
566
Need help choosing the right product?
Our team of riders and experts will be pleased to help you.
Specs
Size
Metric
Imperial
This is a size chart.
Geo
Metric
Imperial
Geometry of this bike.
Reach
Horizontal measurement taken from the middle of the bottom backet to the middle of the headtube.
Stack
Vertical measurement taken from the middle of the bottom bracket to the middle of the headtube.
Effective Top Tube
Horizontal measurement taken from the middle of the seatube to the middle of the headtube.
Actual Top Tube
True length of the top tube taken from the seatube along the toptup to the headtube.
Standover Height
Vertical measurement taken from the ground to the the middle of toptube.
Seat Tube Angle
Angle of the seatube.
Seat Tube Length
Lenght of the seat tube taken from the bottom bracket to the top of the seat tube (the measure is taken alongside the seat tube)
Headtube Angle
Angle of the headtube.
Headtube
Vertical lenght of the headtube.
Chainstay
Horizontal measurement taken from rear axle to the bottom bracket.
Wheelbase
Horizontal measurement between the two wheel axles.
BB Height
Vertical measurement taken from the ground to the bottom bracket (Never taken at sag).
BB Drop
Vertical measurement between the height of the axles and the height of the bottom bracket.
