Specs
TECHNICAL INFORMATION
SPECIFICATION
DETAIL
BICYCLE TYPE
Enduro / Freeride
FRAME MATERIAL
AL 6069 T4, T6
FRAME WEIGHT
4,1 kg / 9.03 lb
REAR TRAVEL
155mm / 170mm
SHOCK LENGTH/STROKE
230x65mm
RECOMMENDED SAG
26-30% / 17-20mm
PIGGY BACK SHOCK COMPATIBLE
Yes
SHOCK BUSHINGS
20x8mm / 30x10mm
RECOMMENDED/MAX. FORK HEIGHT
572mm / 586mm
HEADSET TYPE
ZS44 / ZS56
ICR COMPATIBLE
No
WHEELS SIZE
27.5’’ - 27.5’’
MAX. REAR TYRE DIMENSION - ETRTO
65mm - Ø584mm
REAR BRAKE MOUNTING TYPE
Postmount 200mm
REAR BRAKE ROTOR MAX. SIZE
223mm
SEATPOST/SEAT CLAMP DIAMETER
34,9mm / 38,5mm
SEATPOST INSERTION MAX.
S : 250mm / M-L-XL : 275mm
BOTTOM BRACKET TYPE
Press Fit BB 92mm
CHAIN GUIDE
ISCG 05
RECOMMENDED/MAX. CHAINRING TEETH
32T / 34T
CHAIN LINE
55
REAR HUB DIMENSION
148x12mm
REAR AXLE DIMENSION
Maxle standard, 180mm, M12, P1.75mm
UDH HANGER
No
SHOCK ANCHOR ADJUSTMENT
2 positions
Geometry
GEOMETRY
MEASUREMENT
S
M
L
XL
1 - SEAT TUBE LENGTH
380
418
440
465
2 - SEAT TUBE ANGLE
77,2°
77,2°
77,2°
77,1°
3 - HEAD TUBE ANGLE
64°
64°
64°
64,5°
4 - HEAD TUBE LENGTH
110
115
120
125
5 - WHEELBASE
1216
1238
1265
1292
6 - TOP TUBE LENGTH
586
607
633
666
7 - CHAIN STAY LENGTH
434
434
434
434
8 - BOTTOM BRACKET HEIGHT
-12
-12
-12
-12
9 - FORK LENGTH
572
572
572
572
10 - FORK OFFSET
37
37
37
37
11 - REACH
445
465
490
520
12 - STACK
619
624
628
635
Need help choosing the right product?
Our team of riders and experts will be pleased to help you.
Specs
Size
Metric
Imperial
This is a size chart.
Geo
Metric
Imperial
Geometry of this bike.
Reach
Horizontal measurement taken from the middle of the bottom backet to the middle of the headtube.
Stack
Vertical measurement taken from the middle of the bottom bracket to the middle of the headtube.
Effective Top Tube
Horizontal measurement taken from the middle of the seatube to the middle of the headtube.
Actual Top Tube
True length of the top tube taken from the seatube along the toptup to the headtube.
Standover Height
Vertical measurement taken from the ground to the the middle of toptube.
Seat Tube Angle
Angle of the seatube.
Seat Tube Length
Lenght of the seat tube taken from the bottom bracket to the top of the seat tube (the measure is taken alongside the seat tube)
Headtube Angle
Angle of the headtube.
Headtube
Vertical lenght of the headtube.
Chainstay
Horizontal measurement taken from rear axle to the bottom bracket.
Wheelbase
Horizontal measurement between the two wheel axles.
BB Height
Vertical measurement taken from the ground to the bottom bracket (Never taken at sag).
BB Drop
Vertical measurement between the height of the axles and the height of the bottom bracket.
