FRAME
META POWER SX 800, 180 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
MOTOR
BOSCH Performance Line CX Gen5 — 120 Nm
BATTERY
BOSCH Powertube 800Fully integrated main battery, 800 WhBOSCH 4A Battery Charger. Compact size & lightweight
DISPLAY
BOSCH Kiox 400C : Integrated and colored display providing a large range of information : speed, ride mode, battery range, charge level, fitness data, elevation gain, altitude and even navigation.BOSCH System Controller, ON/OFF switch, assist mode level, battery charge levelSwitch: BOSCH Mini Remote, mode switch, walk assist, light switch
SHOCK
FOX Float X2 Factory230 x 65 mm, 2-postion (open/firm) lever, HSC, LSC, HSR, LSR
FORK
FOX 38 Factory E-Bike, 180 mm29", Grip X2 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset, 3 spacers
HEADSET
ACROS ZS56/ZS66Alloy cups, stainless steel & sealed bearings
STEM
RIDE ALPHA 4040 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Longneck 2.1Soft compound, single clamp, black
BRAKES
TRP DH-R EVO PRO, 4 pistons, resin padsRear rotor: TRP RS05 203 mm - Front rotor: TRP RS05 220 mm6-bolt, 2.3 mm width
SHIFTERS
SRAM Eagle 9012s
CHAIN GUIDE
RIDE ALPHA32-34t
REAR DERAILLEUR
SRAM Eagle 9012s
CRANKSET
E13 Helix Core E*Spec, 155 mm crank arms, BoschChainring: SRAM XX T-Type E-MTB, 34t for Bosch system, direct mount
CHAIN
SRAM GX T-Type12s, Flattop
CASSETTE
SRAM GX T-Type12s, 10-52t
RIMS
DT SWISS FR541Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
HUBS
Rear: DT SWISS 370 Hybrid - Front: DT SWISS 370Rear: 28h, sealed bearings, 12 x 148 mm, 24t, SRAM XD - Front: 28h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
Included with wheelset
TYRES
Rear: MAXXIS Minion DHRII 27.5'' - Front: MAXXIS ASSEGAI 29''Rear: 27.5x2.50 WT, 3C MaxxTerra, Double Down, TR - Front: 29x2.50 WT, 3C MaxxGrip, New EXO+, TR
SEAT POST
ONE UP V331.6 mm, 150 mm on S, 180 mm on M, 210 mm on L/XL
SADDLE
FIZIK Terra Aidon X5145 mm width, Kium Mobius rails
WEIGHT
25,5 kg / 56.22 lbsMinimum weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
CRANKBROTHERS Stamp 1
COLOUR
Pure BlackShiny Finish
ACCESSORIES
RideWrap Lotus Pro™ protection film applied, motor protector, chain stay protector, seat stay protector, FIDLOCK base, fork fender, CRANKBROTHERS STAMP 1 pedals
