FRAME
META POWER TR V4, 140 mm29", Alloy 6066, triple butted tubes, T4, T6.
MOTOR
BOSCH Performance Line CXMax. torque: 85N.m, 250W
BATTERY
BOSCH PowerTube 625, 625WhBOSCH 4A Charger, Compact size & lightweightCompatible w/BOSCH PowerMore 250 for extra range
DISPLAY
BOSCH System ControllerBOSCH Mini Remote currently not available in the USA
SHOCK
ROCKSHOX Super Deluxe Coil Ultimate210 x 55 mm, RC2T Adj. Hydraulic Bottom Out, HSC, LSC, rebound, 2-position compression (open/firm). Spring rates : 350lbs on S, 350 on M, 400lbs on L, 450lbs on XL
FORK
ROCKSHOX Lyrik Ultimate, 160 mm travel29", DebonAir+ W/ButterCups, Charger 3 RC2 W/ButterCups damper, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token
HEADSET
ACROS ZS56 / ZS66Alloy cups, sealed bearings
STEM
RIDE ALPHA 40 EXTERNAL40 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XLInternal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
TRP DH-R Evo, 4 pistons, resin padsRotors: TRP R1 220 mm, 6-bolt
SHIFTERS
SRAM GX Eagle12s
CHAIN GUIDE
RIDE ALPHA Upper Guide32-34t
REAR DERAILLEUR
SRAM GX Eagle12s
CRANKSET
E13 E*Spec Plus Bosch CX, 160 mm crank armsChainring: E13 E*Spec Plus Bosch CX, 34t, direct mount
CASSETTE
SRAM XG-1275 Eagle12s, 10-52t
RIMS
Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 SplineRear: 29'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
HUBS
Rear: DT SWISS 350 - Front: DT SWISS 350Rear: 28h, 12 x 148 mm, sealed bearings, 24t, e-bike specific, Sram XD - Front: 28h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
DT SWISS Hybrid 1Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
TYRES
Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic MaryRear: 29" x 2.4", Super Trail, Addix SpeedGrip, Tubeless Easy - Front: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy
SEAT POST
KS Lev Integra31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote
SADDLE
FIZIK Terra Aidon X3145 mm width, Kium Mobius rails
WEIGHT
24.3 kg / 53.57 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
RIDE ALPHA CNC
COLOUR
Dark SlateMatte Finish
ACCESSORIES
Motor protector, chainstay protector, seatstay protector
