FRAME
META POWER TR V4, 140 mm travel29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
MOTOR
SHIMANO DU-EP800250 W, 85 Nm
BATTERY
SHIMANO BT-E8036630Wh internal batterySHIMANO Europlug (CEE 7/7 norm) battery charger(a plug adapter is necessary for customers living in countries using different standards)
DISPLAY
SHIMANO SC-EM800LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication)
SHOCK
RockShox Deluxe Select +210 x 55 mm, rebound, threshold adjustment
FORK
ROCKSHOX Lyrik Select +, 150 mm travel29", Debonair, Charger 2.1 RC damper, compression, rebound, Boost (15 x 110 mm), 42 mm offset
HEADSET
ACROS ZS56 / ZS66Alloy cups, sealed bearings
STEM
RIDE ALPHA Freeride 5050 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 E-Bike31,8 mm, 780 mm width, 20 mm rise, Alloy 6061, electric wire internal routing
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
SRAM Guide RE, 4 pistonsRotors : SRAM Centerline 220mm, 6 holes
SHIFTERS
SRAM GX Eagle12s, Single Click
CHAIN GUIDE
RIDE ALPHA EP832-34t
REAR DERAILLEUR
SRAM GX Eagle12s
CRANKSET
SHIMANO FC-EM900 160 mm crank armsChainring : E13 E*Spec Plus 32t, Narrow-Wide, direct mount
CASSETTE
SRAM XG-1275 Eagle12s, 10-52t
RIMS
DT SWISS H1900 Spline29'', 28h, 30 mm inner width
HUBS
Rear: DT SWISS 370 - Front: DT SWISS 370Rear: 28h, 12 x 148 mm, sealed bearings, 18t, Sram XD, e-bike specific - Front: 28h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
DT SWISS Hybrid 1Straightpull, 2.34 / 2.0 mm, triple butted, stainless, with ProLock, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS DHR IIRear: 29 x 2.4, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 29 x 2.4, 3C MaxxTerra, EXO+, Tubeless Ready
SEAT POST
KINDSHOCK Lev Si31,6 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L & XL, SouthPaw alloy remote
SADDLE
FIZIK Terra Aidon X3145 mm width, Kium Mobius rails
WEIGHT
24,4 kg / 53,79 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED
RIDE ALPHA CNC
COLOUR
Dark SlateMatte Finish
ACCESSORIES
Motor protector, chainstay protector, seatstay protector
