FRAME
META SX V4, 160 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
SHOCK
OHLINS TTX22 M.2 Coil230 x 62.5 mm, HSC, LSC, rebound, climb mode. Spring rates: 343lbs on S, 388lbs on M, 434lbs on L, 480lbs on XL
FORK
OHLINS RXF38 m.2 Air, 170 mm travel29", TTX 18 damper, Ramp Up chamber, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset
HEADSET
ACROS ZS44/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA Freeride 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
SHIMANO XT, 4 pistons, I-Spec EV compatibleRotors: GALFER Disc Wave 203 mm, 6 holes
REAR DERAILLEUR
SHIMANO XT12s
BOTTOM BRACKET
SHIMANO BBMT800Pressfit
CRANKSET
SHIMANO XT, 170 mm crank arms, BoostChainring: SHIMANO XT, 32t, Dynamic Chain Engagement + Technology
CASSETTE
SHIMANO XT12s, 10-51t
RIMS
Rear: DT SWISS EX511 27.5'' - Front: DT SWISS EX511 29''Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
HUBS
Rear: DT SWISS 350 - Front: DT SWISS 350Rear: 28h, sealed bearings, 12 x 148 mm, MicroSpline, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black
SPOKES/NIPPLES
DT SWISS CompetitionStraightpull, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
TYRES
Rear: SCHWALBE Big Betty - Front: SCHWALBE Magic MaryRear: 27.5" x 2.4", Super Trail, Addix Soft, Tubeless Easy - Front: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy
SEAT POST
KS Lev Integra34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote
SADDLE
SDG Bel Air V3 Atmos140 mm width, Lux-Alloy Rails
WEIGHT
15,9 kg / 35.05 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
ÖHLINS YellowMatte Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector
