FRAME
META SX V4, 160 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
SHOCK
ROCKSHOX Deluxe Select230 x 62.5 mm, R damper, DebonAir Linear, rebound, threshold adjustment, 1 Token neg. 4 Tokens pos.
FORK
ROCKSHOX Domain R, 170 mm travel29", Debonair, rebound, Boost (15 x 110 mm), 44 mm offset, 1 Token
HEADSET
ACROS ZS44/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA Freeride 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA DHUltra-soft compound, single clamp, black
BRAKES
SRAM Guide T, 4 pistons, MatchMaker compatibleRotors: SRAM G2 CleanSweep 200 mm, 6-bolt
SHIFTERS
SRAM SX Eagle12s
REAR DERAILLEUR
SRAM SX Eagle12s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
Rear: E13 LG1 DH Base 27.5'' - Front: E13 LG1 DH Base 29''Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
Rear: FORMULA DCL-348A - Front: FORMULA DC-711Rear: 32h, 12 x 148 mm, sealed bearings, Shimano Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings
SPOKES/NIPPLES
SAPIM RACEJ-Bend 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5" x 2.4", WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 29" x 2.5", WT, 3C MaxxTerra, EXO, Tubeless Ready
SEAT POST
RIDE ALPHA34,9 mm, 400 mm on S/M, 450 mm on L/X
SADDLE
SDG Bel Air V3140 mm width, Steel Rails
WEIGHT
15,7 kg / 34.61 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerance.
COLOUR
Heritage GreenMatte Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector
