FRAME
2025 META SX V5, 165 mm travel29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
SHOCK
FOX Float X2 Factory230 x 65 mm, HSC, HSR, LSR, 2-pos lever, 0.3 spacer
FORK
FOX 38 Factory, 170 mm travel29", rebound, Boost (15 x 110 mm), HSC, LSC, HSR, LSR, 44mm offset, 1 Token
HEADSET
ACROS ZS56/ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA 4040 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Longneck V2.1Black clamp
BRAKES
SHIMANO New XT, 4 pistons, resin padsRotors: SHIMANO MT905, 203 mm, 6-bolts
SHIFTERS
SRAM Eagle 9012s
REAR DERAILLEUR
SRAM Eagle 9012s
BOTTOM BRACKET
SRAM DUB92 MTB WIDEPressfit
CRANKSET
SRAM X0 T-Type, 165 mm crank armsChainring: SRAM X0 T-Type, 32t
CASSETTE
SRAM GX T-Type12s, 10-52t
RIMS
DT SWISS EX1700 — Rear: 27.5'', 32h, 28 mm inner width - Front: 29'', 32h, 28 mm inner width
HUBS
DT SWISS 350Rear: 32h, sealed bearings, 12 x 148 mm, Sram XD - Front: 32h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
DT SWISS CompetitionStraightpull
TYRES
Rear: MAXXIS DHR II - Front: MAXXIS AssegaiRear: 27.5''x2.5'' WT, 3C MaxxTerra, New EXO+, Tubeless Ready - Front: 29''x2.5'' WT, 3C MaxxGrip, New EXO+, Tubeless Ready
SEAT POST
ONE UP V331,6 mm, travel: 125 mm on S, 170 mm on M and 190 mm on L/XL, SouthPaw alloy remote
SADDLE
FIZIK Terra Ridon X5145 mm, Alloy rails
WEIGHT
16,3 kg / 35.93 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure WhiteShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender, FIDLOCK base, seatpost adapter.
