FRAME
META TR V4, 140 mm travel29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
SHOCK
ROCKSHOX Super Deluxe Coil Ultimate210 x 55 mm, RCT damper, LSC, rebound, 2-position (open/firm). Spring rates: 350lbs on S/M, 400lbs on L, 450lbs on XL
FORK
ROCKSHOX Lyrik Ultimate, 160 mm travel29", Charger 2.1 damper, DebonAir, LSC, HSC, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens
HEADSET
ACROS ZS44 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA Freeride 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI Elite MotionSoft pro compound, single clamp, black
BRAKES
TRP DH-R Evo, 4 pistonsRotors: TRP R1 203 mm, 6-bolt, 2.3 mm width
SHIFTERS
SRAM GX Eagle12s
REAR DERAILLEUR
SRAM GX Eagle12s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
SRAM GX Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM GX Eagle, 32t, Narrow-Wide
CASSETTE
SRAM XG-1275 Eagle12s, 10-52t
RIMS
DT SWISS EX51129'', 28h, 30 mm inner width
HUBS
Rear: DT SWISS 350 - Front: DT SWISS 350Rear: 28h, sealed bearings, 12 x 148 mm, XD driver, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black
SPOKES/NIPPLES
DT SWISS CompetitionStraightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS Dissector - Front: MAXXIS DHR IIRear: 29" x 2.40", WT, EXO+, 3C MaxxTerra, Tubeless Ready - Front: 29" x 2.40", WT, EXO, 3C MaxxGrip, Tubeless Ready
SEAT POST
KS Lev Integra34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote
SADDLE
SDG Bel Air V3 Atmos140 mm width, Lux-Alloy Rails
WEIGHT
15,9 kg / 35.05 lbAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
BrushedShiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector
