FRAME
SUPREME DH V5, 220 mm travel 29/27.5'', Alloy 6066, triple butted tubes, T4, T6
SHOCK
FOX FLOATX2 Factory250 x 75 mm, HSC, LSC, HSR, LSR, 0.3 spacer x3
FORK
FOX 40 Factory, 203 mm travel29", Grip2 damper, HSC, LSC, HSR, LSR. Boost (20 x 110 mm), 52 mm offset, 2 spacers.
HEADSET
ACROS ZS56 / ZS56Alloy cups, sealed bearings
STEM
RIDE ALPHA DH 4040 mm extension, direct mount, 31.8 mm
HANDLEBAR
RIDE ALPHA R2731.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
ODI LongneckSoft pro compound, single clamp, black
BRAKES
TRP DH-R Evo, 4 pistons, resin padsRotors: TRP R1 223 mm, 6-bolt, 2.3 mm width
CHAIN GUIDE
E13 LG1 + Bottom Guide32-34t
REAR DERAILLEUR
SRAM GX DH7 sp
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
TRUVATIV Descendant DH, 165 mm crank arms, DUBChainring: TRUVATIV Descendant DH X-Sync, 34t
CASSETTE
E13 DH 7 Speed Integrated Cassette7 sp, 9-24t
RIMS
E13 GRAPPLER Race Alloy — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
Rear: E13 GRAPPLER Race Alloy - Front: E13 GRAPPLER Race AlloyRear: 32h, sealed bearings, 12 x 157 mm, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, black
TYRES
Rear: SCHWALBE TACKY CHAN - Front: SCHWALBE TACKY CHANRear: 27.5''x2.4'', Super DH, Addix Ultra Soft, Tubeless Easy - Front: 29"x2.4", Super DH, Addix Ultra Soft, Tubeless Easy
SEAT POST
RIDE ALPHA Super Light31.6 mm, 250 mm, Alloy 7075
SADDLE
FIZIK Gravita Alpaca X5130 mm width, S-Alloy rails
WEIGHT
18,1 kg / 39,9 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Clear SilverShiny Finish
ACCESSORIES
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard, tubeless valves, FOX 40 fork fender
