FRAME
SUPREME DH V5, 220 mm travel — 29/27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
SHOCK
FOX DHX2 Factory — 250 x 75 mm, HSC, LSC, HSR, LSR — 425lbs on S, 475lbs on M, 525lbs on L, 575lbs on XL
FORK
FOX 40 Factory, 200 mm — 29", Grip X2, HSR, LSR, HSC, LSC, Boost (20 x 110 mm), 52 mm offset
HEADSET
CANECREEK SERIE 40 — Alloy cups, sealed bearings
STEM
BURGTEC MK3 DH — 45 mm extension, direct mount, 31.8 mm
HANDLEBAR
BURGTEC Ride Wide — 31.8 mm, 800 mm width, 30 mm rise, Alloy 6061
GRIPS
ODI Longneck V2.1 — Single clamp, black
BRAKES
SRAM Maven Silver, 4 pistons, resin pads — Rotors: SRAM HS2 220 mm, 6-bolt, 2.0 mm thickness
CHAIN GUIDE
E13 LG1 — 32-34t
REAR DERAILLEUR
SRAM GX DH — 7s
BOTTOM BRACKET
SRAM DUB — Pressfit
CRANKSET
SRAM Descendant DH, 165 mm crank arms, DUB — Chainring: SRAM Descendant DH, 34t
CASSETTE
SRAM PG-720 DH — 7s, 11-25t
RIMS
Rear: DT SWISS FR571 - Front: DT SWISS FR541 — Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
HUBS
DT SWISS 350 — Rear: 32h, sealed bearings, 12 x 157 mm, SHIMANO Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm
SPOKES/NIPPLES
DT SWISS Competition — Straightpull
TYRES
Rear: MAXXIS Minion DHR II - Front: MAXXIS High Roller III — Rear: 27.5x2.50WT 3C MaxxTerra / DH Casing / TR - Front: 29x2.50WT 3C MaxxGrip / DH Casing / TR
SEAT POST
RIDE ALPHA — 31.6 mm, 250 mm length
SADDLE
FIZIK Gravita Alpaca X5 — S-Alloy rails, Team edition
WEIGHT
- kg / - lbs — Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure White — Shiny Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector, shuttle pad, fork bumpers, FOX 40 fender
