FRAME
SUPREME DH V5, 220 mm travel — 29/27.5'', Alloy 6066, triple butted tubes, T4, T6.
SHOCK
ROCKSHOX Vivid Coil Ultimate DH — 250 x 75 mm, HSC, LSC, LSR, rebound. — Spring rates: 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL
FORK
ROCKSHOX Boxxer Ultimate, 200 mm travel — 29'', Charger 3 damper, HSC, LSC, HSR, LSR, Boost (20 x 110 mm), 52 mm offset
HEADSET
ACROS ZS56/ZS56 — Alloy cups, sealed bearings
STEM
RIDE ALPHA DH — 40 mm extension, 31.8 mm
HANDLEBAR
RIDE ALPHA — 31.8 mm, 780 mm on S/M/L, 800 mm on XL, rise 27
GRIPS
RIDE ALPHA Mushroom — 132 mm, single clamp, black
BRAKES
SRAM Maven Bronze, 4 pistons, sintered pads — Rotors: SRAM HS2 220 mm, 6-bolts, 2.0 mm width
CHAIN GUIDE
E13 LG1 — 32-34t
REAR DERAILLEUR
SRAM GX Eagle — 7s
BOTTOM BRACKET
SRAM DUB — Pressfit
CRANKSET
SRAM Descendant DH, 165 mm crank arms, DUB — Chainring: SRAM Descendant DH, 34t
CASSETTE
SRAM PG-720 DH — 7s, 11-25t
RIMS
DT SWISS F1900 Classic — Rear: 27.5'', 32h, 30 mm inner width, 12 x 157 mm - Front: 29'', 32h, 30 mm inner width, 20 x 110 mm
HUBS
Included with wheelset
SPOKES/NIPPLES
Included with wheelset
TYRES
Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic Mary — Rear: 27.5''x2.4'', Super DH, Addix Ultra Soft, Tubeless Easy - Front: 29''x2.4", Super DH, Addix Ultra Soft, Tubeless Easy
SEAT POST
RIDE ALPHA — 31.6 mm, 250 mm
SADDLE
FIZIK Gravita Alpaca X5 — 130 mm width, S-Alloy rails, Team edition
WEIGHT
18,7 kgs - 41,22 lbs — Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Pure White — Shiny Finish
ACCESSORIES
Chainstay protector, seatstay protector, fork bumpers, downtube protector, Rockshox fender
