FRAME
T.E.M.P.O., 125 mm travel29'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings
SHOCK
ROCKSHOX Deluxe Select+210 x 50 mm, RT damper, DebonAir Progressive, rebound, 2 positions comp, 1 Token neg. 3 Tokens pos.
FORK
ROCKSHOX Pike, 140 mm travel29", Rush RC Damper, DebonAir+, LSC, rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token
HEADSET
ACROS ZS56 / ZS56Alloy cups, sealed bearings, Integrated cable routing
STEM
RIDE ALPHA 4040 mm extension, 31,8 mm
HANDLEBAR
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
GRIPS
RIDE ALPHA DHUltra-soft compound, single clamp, black
BRAKES
TRP Trail Evo, 4 pistons, resin padsRotors: TRP R1 203 / 180 mm, 6-bolt, 2.3 mm thickness
SHIFTERS
SRAM NX Eagle12s
REAR DERAILLEUR
SRAM SX Eagle12s
BOTTOM BRACKET
SRAM DUBPressfit
CRANKSET
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, BoostChainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide
CASSETTE
SRAM PG-121012s, 11-50t
RIMS
SPANK Spike Race 33 — 29'', 28h, 28 mm inner width
HUBS
Rear: FORMULA DCL-348A - Front: FORMULA DC-711Rear: 28h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 28h, sealed bearings, 15 x 110 mm
SPOKES/NIPPLES
SAPIM D-LightJ-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, black
TYRES
Rear: MAXXIS Dissector - Front: MAXXIS DHR IIRear: 29" x 2.4" WT, dual compound, EXO, Tubeless Ready - Front: 29" x 2.4" WT, 3C MaxxGrip, EXO, Tubeless Ready
SEAT POST
KINDHSOCK Ragei31.6 mm, 150 mm on S, 170 mm on M, 190 mm on L/XL
SADDLE
SDG Bel Air V3140 mm width, Steel Rails
WEIGHT
15,1 kg / 33,2 lbsAverage weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
COLOUR
Dark SlateMatte Finish
ACCESSORIES
Down tube protector, chainstay protector, seatstay protector
