Isolator RC damper featuring three-position Compression adjustment (Open, Pedal, and Firm) with externally-adjustable Rebound providing superior traction, control, and confidence for the rider.
38mm chassis for increased stiffness, perfect for mountain bikes and E-MTBs alike.
Highly tunable DebonAir air spring sits higher in the travel—making the most of Domain’s 150-180mm travel—and offers a smooth, consistent, coil-like feel throughout the stroke. It’s highly tunable and Bottomless Token ready.
Short fender compatible (RockShox fender included).
Maxima Plush damping fluid reduces friction and quiets rebound damper noise.
Maxima Plush Dynamic Suspension Lube reduces friction, lasts longer, and enhances suspension performance ride after ride.
SRAM Model ID: FS-DOMN-GRC-C1
Attributes
Brake Type
Disc
Damping
Isolator RC
Damping Adjustments
External rebound, 3 position compression (open/pedal/firm)
Crown Material
Aluminum
Rake
44mm
Maximum Rotor Size
220mm
Maximum Tire Width
81mm
Primary Color
Black
Spring Adjustments
Air pressure
Spring Type
DebonAir
Steerer Tube
1-1/8''-1.5''
Steerer Tube Material
Aluminum
Lower Tubes Material
Magnesium
Stanchions Material
Aluminum
Stanchions Diameter
38mm
Axle/Hub spacing
15x110mm TA
e-Bike approved
Yes
Need help choosing the right product?
Our team of riders and experts will be pleased to help you.
Specs
Size
Metric
Imperial
This is a size chart.
Geo
Metric
Imperial
Geometry of this bike.
Reach
Horizontal measurement taken from the middle of the bottom backet to the middle of the headtube.
Stack
Vertical measurement taken from the middle of the bottom bracket to the middle of the headtube.
Effective Top Tube
Horizontal measurement taken from the middle of the seatube to the middle of the headtube.
Actual Top Tube
True length of the top tube taken from the seatube along the toptup to the headtube.
Standover Height
Vertical measurement taken from the ground to the the middle of toptube.
Seat Tube Angle
Angle of the seatube.
Seat Tube Length
Lenght of the seat tube taken from the bottom bracket to the top of the seat tube (the measure is taken alongside the seat tube)
Headtube Angle
Angle of the headtube.
Headtube
Vertical lenght of the headtube.
Chainstay
Horizontal measurement taken from rear axle to the bottom bracket.
Wheelbase
Horizontal measurement between the two wheel axles.
BB Height
Vertical measurement taken from the ground to the bottom bracket (Never taken at sag).
BB Drop
Vertical measurement between the height of the axles and the height of the bottom bracket.
