Product Description
FEATURES
Rigorously tested by EFBE. Passed TRI-TEST® GR. Certified for freeride and downhill mountain bikes
Machined from solid 7075 T73 aluminum
Ultra-wide clamp
Thin headset spacer is required
Not compatible with the FORM aluminium handlebars
SPECIFICATIONS
35mm clamp diameter
46mm length
85mm width
150g (172g including all 8 bolts)
M6 x 1.0 x 18mm / 20mm stainless steel bolts
INTENDED USE
Downhill / Freeride
RECOMMENDATIONS
Handlebar clamps to be tightened with equal gaps on top and bottom. All stems have MAX Torque specs etched onto the stem body. Note that MAX torque specs are just that, a maximum rating. For most purposes, 5-6nm should be adequate.
